PLC Programming from Beginner to Paid Professional: Learn How to Integrate & Program Point IO Hardware in RSLogix 5000 with Demo Videos (Part 4 of 4):

This playbook is the 4th in my PLC Programming series. It is an exhaustive collection of my tutorials and demo videos on how to work with Allen Bradley’s Point IO 1734 hardware.

First, you will be introduced to this hardware component from Rockwell Automation. Next, you will learn how to connect to it from a network. With my demo videos, you will also learn how to wire a SICK sensor into a Point IO input and test the hardware in Studio 5000.

You will find this book and the accompanying demo videos very helpful if you are an electrician, an instrumentation technician, a manufacturing operator, an automation professional or engineer looking to looking to progress their career or level up their knowledge of Point IO digital input wiring and testing, and to acquire advanced PLC programming skills.

There are 11 chapters in this book and are accompanied with 9 in-depth HD demo videos that you can download. These videos simplify everything you need to understand, and help you speed up your learning of Point IO Hardware programming and integration. There is also a link in this book for you to download my PLC programs (codes) for your revision.

I start with an overview of the Point IO modules, and then move on to IP addressing, web server, and power supply overview. Then I proceed to Point IO integration into Studio 5000, including how to create the Point IO definition within the CompactLogix 1769-L24ER-QB1B PLC and validating the communication. Finally, I take a special look at a Point IO real panel example. This is a Point IO panel used for a plant control which I commissioned myself few months ago.

So, after studying this book and the demo videos, you should develop a hands-on approach to the programming and integration of Point IO into Studio 5000 Rockwell Environment, and be able to use it in real world industrial applications.

The best way to master PLC programming is to use real world situations. The real-world scenarios and industrial applications developed in this book and its accompanying video demos will help you learn better and faster many of the functions and features of Studio 5000 platform.

The methods presented in the demo videos are those that are usually employed in the real world of industrial automation, and they may be all that you will ever need to learn. The information in this book and the demo videos is very valuable, not only to those who are just starting out, but also to any other skillful PLC programmer, no matter their skill level.

Merely having the user manual of a Point IO hardware, or referring to its help contents, is far from enough in learning this critical component of a distributed control system. Therefore, this book and the accompanying demos are extremely useful for learning how to reduce costs of installation and the need of multiple PLCs in many situations.

One of the questions I get asked often by beginners is, where can I get a free download of RSLogix software to practice? I provide later in this book links to a free version of the RSLogix Micro Starter Lite (which is essentially the same programming environment as the RSLogix 500 Pro) and a free version of the RSLogix Emulate 500.

In Chapter 10, I also provide links to download the demo edition of RSLogix 5000 / Studio 5000 Logix Designer to your system. Make sure you create an account at RockwellAutomation.com first. So, you don’t even need to have a full-blown PLC to learn, run and test your ladder logic programs.

I do not only show you how to get these important Rockwell Automation software for free and without hassle, I also show with HD videos how to install, configure, navigate and use them to write ladder logic programs.
